Add New Mechanical Nodes

Step-by-step

  1. Select Add New Heating Element

  2. Choose the type (e.g., Radiator or Air Handling Unit)

  3. Assign a Name

  4. Set dimensions (Width, Depth, Height)

  5. Input Load Rating

    System Volume,

    Pressure Drop.

  6. Set the Connection Height above the floor for inlets and outlets.

  7. Click Create to add the node.

The Mechanical Node can be found in the Design mode, in the relevant drop down menu.

Modify Existing Mechanical Nodes

Step-by-step

  1. Select the existing Mechanical Node from the list to modify or delete it.

  2. Adjust the Name, Dimensions, Load Rating, or other technical properties.

  3. Click Update.

All instances of the node in your design will be updated automatically.
