🔢 Results

View Results

Click on Results to run the calculations for your project.

Results will display over each component in the design, generated based on the Settings and specific properties in your layout.

  1. Zoom In and Out: Use your mouse scroll to adjust the level of detail visible. Zooming in provides detailed data for each component while zooming out displays only key data points to reduce clutter.

  2. Pin Results: When hovering over a component, click the Pin icon to prioritize key data. Pinned results will remain visible as you zoom out.

  3. Quick Summary: Hover over components to view a data summary without activating filters.

If the calculations do not complete and the issue is unclear, refer to the Troubleshooting section for guidance.
